MODULAR CUBE PONTOONS
Robust, stable pontoon with unrivalled versatility
Our Modular Cube Pontoons redefine stability and versatility, making them suitable for both permanent and temporary installations in a variety of locations. Crafted from High-Density Polyethylene (HDPE), these cubes are engineered to withstand extreme weather conditions while offering exceptional stability. They quickly connect by inserting a connection pin and turning it 45 degrees, locking it securely in place. With each cube weighing just 7kg, they're easy to move and assemble into virtually any shape or size.
The cubes feature a hard-wearing, non-slip surface for safe usage in all conditions. Fully UV-stabilized and corrosion-resistant due to their HDPE composition, these cubes require minimal maintenance and are environmentally friendly, being recyclable.
Modular Cube Pontoons are renowned for their flexibility, allowing them to adapt to rough seas without sustaining damage. With an unladen draft of just 25mm, they can be utilized in shallow waters when necessary.
We stock both standard cubes and Low Profile Cubes to cater to diverse client needs. The standard cube specifications are as follows:
Dimensions: 500mm x 500mm x 400mm
Weight: 7Kg
Compression Load: 3500Kg/sqm
Load Capacity: 350Kg/sqm
Material: High-Density Polyethylene
Diagonal Lug Tensile Strength: 1950kg (test speed 50mm/min)
For clients requiring a lower freeboard, our Low Profile Cube specifications are as follows:
Dimensions: 500mm x 500mm x 250mm
Weight: 5.4Kg
Compression Load: 3500Kg/sqm
Load Capacity: 240Kg/sqm
Material: High-Density Polyethylene
Diagonal Lug Tensile Strength: 1950kg (test speed 50mm/min)
When higher load capacity is necessary, the cubes can be double or triple stacked, proportionally increasing the safe working load.
Complementing our cube inventory, we stock a wide range of accessories to facilitate easy pontoon system installation, including Cleats, Fenders, Handrails, Winches, Access Ladders, Lights, Lifting Gantries, and Mooring Attachments.
Our experienced engineers employ 3D CAD systems to design your pontoon, ensuring it aligns perfectly with your specifications. Our installation teams, with their wealth of experience, guarantee that the completed pontoon surpasses your expectations.
Additionally, we maintain a substantial rental stock of Modular Cubes and associated accessories, available for both short and long-term hire throughout the UK."
